Jual Digital Theodolite TOPCON DT-200/200L
Lightweight and compact angular measurement device
The DT-200 series integrates the same high-quality advanced absolute circle reading technology found in Topcon high-performance total station products for high accuracy field calculations.
Jual Digital Theodolite TOPCON DT-200/200L
Model | DT-205 | DT-207 | DT-209 |
Angle Measurement | Accuracy | 5" | 7" | 9" |
Method | Absolute Reading | Absolute Reading | Absolute Reading |
Detecing | Horizontal : 2 Sides | Horizontal : 2 Sides | Horizontal : 1 Sides |
Vertical : 1 Side | Vertical : 1 Side | Vertical : 1 Side |
Min Reading | 1"/5" | 5"/10" | 10"/20" |
0.5 mgon / 1 mgon | 1 mgon / 2 mgon | 2 mgon / 5 mgon |
Diameter Circle | 71mm (2.75") | 71mm (2.75") | 71mm (2.75") |
Telescope | Magnification | 30x | 30x | 26x |
Length | 149 mm (5.8") | 149 mm (5.8") | 149 mm (5.8") |
Objective Lens | 45 mm (1.7") | 45 mm (1.7") | 40 mm (1.7") |
Field Of View | 1°30' | 1°30' | 1°30' |
Resolving Power | 2.5" | 2.5" | 2.5" |
Minimum Focus | 0.9m (2.9') | 0.9m (2.9') | 0.9m (2.9') |
Stadia Ratio | 100 | 100 | 100 |
Stadia Constant | 0 | 0 | 0 |
Sighting Collimator | Double | Double | Double |
Laser Pointer | Method | N/A | N/A | N/A |
Weve Length / Power | N/A | N/A | N/A |
Laser Class | N/A | N/A | N/A |
Display | Unit | 2 Sides | 2 Sides | 1 Sides |
LCD 7 Segment | LCD 7 Segment | LCD 7 Segment |
Data Output | Serial Signal Connector | RS-232C | N/A | N/A |
Illumination | Display | Yes | Yes | Yes |
Reticle | Yes | Yes | N/A |
Compensator | Tilt Sensor | Vertical | N/A | N/A |
Compensating Range | ±3' | N/A | N/A |
Optical Plummet | Magnification | 3x | 3x | 3x |
Field Of View | 3° | 3° | 3° |
Focusing | 0.5 m~∞ | 0.5 m~∞ | 0.5 m~∞ |
Level Sensitivity | Plate Level | 40"/2mm | 40"/2mm | 60"/2mm |
Circular Level | 10'/2mm | 10'/2mm | 10'/2mm |
Water Protection | Standard | IP66 | IP66 | IP66 |
Power Supply | Battery | 4 AA Batteries | 4 AA Batteries | 4 AA Batteries |
Operating Time | Theodolite Only | 140h | 150h | 170h |
Laser Only | N/A | N/A | N/A |
Theodolite and Laser | N/A | N/A | N/A |
Operating Temp | | - 68°F ± 122°F | - 68°F ± 122°F | - 68°F ± 122°F |
(-20 °C ± 50°C) | (-20 °C ± 50°C) | (-20 °C ± 50°C) |
Weight | | 9 Lbs (4,1Kg) | 9 Lbs (4,1Kg) | 7.5 Lbs (3.4Kg) |
|
Model | DT-205L | DT-207L | DT-209L |
Angle Measurement | Accuracy | 5" | 7" | 9" |
Method | Absolute Reading | Absolute Reading | Absolute Reading |
Detecing | Horizontal : 2 Sides | Horizontal : 2 Sides | Horizontal : 1 Sides |
Vertical : 1 Side | Vertical : 1 Side | Vertical : 1 Side |
Min Reading | 1"/5" | 5"/10" | 10"/20" |
0.5 mgon/1 mgon | 1 mgon/2 mgon | 2 mgon/5 mgon |
Diameter Circle | 71mm (2.75") | 71mm (2.75") | 71mm (2.75") |
Telescope | Magnification | 30x | 30x | 26x |
Length | 149 mm (5.8") | 149 mm (5.8") | 149 mm (5.8") |
Objective Lens | 45 mm (1.7") | 45 mm (1.7") | 40 mm (1.7") |
Field Of View | 1°30' | 1°30' | 1°30' |
Resolving Power | 2.5" | 2.5" | 2.5" |
Minimum Focus | 0.9m (2.9') | 0.9m (2.9') | 0.9m (2.9') |
Stadia Ratio | 100 | 100 | 100 |
Stadia Constant | 0 | 0 | 0 |
Sighting Collimator | Double | Double | Double |
Laser Pointer | Method | Focusing | Focusing | Focusing |
Weve Length / Power | 633nm/0.6mW | 633nm/0.6mW | 633nm/0.6mW |
Laser Class | Class II | Class II | Class II |
Display | Unit | 2 Sides | 2 Sides | 1 Sides |
LCD 7 Segment | LCD 7 Segment | LCD 7 Segment |
Data Output | Serial Signal Connector | RS-232C | N/A | N/A |
Illumination | Display | Yes | Yes | Yes |
Reticle | Yes | Yes | N/A |
Compensator | Tilt Sensor | Vertical | N/A | N/A |
Compensating Range | ±3' | N/A | N/A |
Optical Plummet | Magnification | 3x | 3x | 3x |
Field Of View | 3° | 3° | 3° |
Focusing | 0.5 m~∞ | 0.5 m~∞ | 0.5 m~∞ |
Level Sensitivity | Plate Level | 40"/2mm | 40"/2mm | 60"/2mm |
Circular Level | 10'/2mm | 10'/2mm | 10'/2mm |
Water Protection | Standard | IP66 | IP66 | IP66 |
Power Supply | Battery | 4 AA Batteries | 4 AA Batteries | 4 AA Batteries |
Operating Time | Theodolite Only | 140h | 150h | 170h |
Laser Only | 80h | 80h | 80h |
Theodolite and Laser | 45h | 45h | 45h |
Operating Temp | | - 68°F ± 122°F | - 68°F ± 122°F | - 68°F ± 122°F |
(-20 °C ± 50°C) | (-20 °C ± 50°C) | (-20 °C ± 50°C) |
Weight | | 9.25 Lbs (4,2Kg) | 9.25 Lbs (4,2Kg) | 8 Lbs (3.6Kg) |
PT. Mora Anugerah Berkat adalah perusahaan yang sudah berpengalaman dalam menyediakan/mensupply alat - alat survey equipment untuk sipil/pertambangan salah satu dianatarnya seperti Jual Digital Theodolite TOPCON DT-200/200L , kami juga menyediakan berbagai brand/merk internasional dari USA, Eropa dan China,produk internasional yang kami supply/tawarkan seperti : TOPCON, SOKKIA, SOUTH, NIKON, Hi Target dan lain - lain. kami juga menyediakan Jasa Perbaikan (SERVICE), Jasa Perawatan (Maintenace) dan support untuk KALIBRASI / AKSESSORIES SPAREPART jangan ragu untuk menghubungi kami marketing dan sales kami siap membantu menjawab segala kebutuhan anda.
